Max Media survey app
Field survey app for Max Media that keeps working offline and syncs submissions when signal returns.
Role
Solo full-stack developer — mobile app, backend, admin dashboard
Platform
Android & iOS (Expo/React Native) + web admin dashboard
Timeline
May 2026 to Sep 2026 · ~4 months · 44 commits
Source code: private repository.
| Scope | End-to-end field data collection platform: offline mobile survey app + sync backend + admin web dashboard |
|---|---|
| Surface | Native Android/iOS app (Expo Router) + responsive web admin portal |
| Backend | Node.js + Express 5 REST API (Render), MongoDB Atlas |
| Languages | JavaScript/JSX throughout mobile + backend, TypeScript project config with typed routes enabled |
| Offline | 100% of survey data entry works with zero connectivity; sync is a separate, explicit online-only step |
TL;DR
- Built an offline-first mobile survey app (Expo/React Native) plus a Node/Express + MongoDB backend and a React admin dashboard, so field interviewers can capture a long, branching beverage-consumption questionnaire — with GPS-verified responses — in areas with no signal, then sync it to the cloud and export it into a client-specified 2,500+ column Excel format.
- Every write is treated as if it will be duplicated or retried. A serialized local save queue plus a client-generated survey ID with a server-side idempotent upsert eliminate the duplicate-survey bugs that naive SQLite and MongoDB inserts produce under real field conditions — double-taps, dropped responses, flaky connections.
- GPS reads from the device's own chip (Accuracy.Highest) instead of the faster network-assisted default, and every location check is non-blocking except the initial hard gate — trading a slower fix for one that's actually trustworthy, after field reports of multi-kilometre drift traced back to a stale, coarse cached fix being silently reused.
The problem
Max Media runs door-to-door and spot-intercept market research, tracking consumer awareness and consumption across 60+ beverage brands. The existing process couldn't reliably capture structured survey data outside areas with good connectivity, and the client's downstream reporting pipeline depends on a specific, pre-existing spreadsheet format that a new tool couldn't break.
- Interviewers work in areas with unreliable or no mobile data, so an all-online tool would simply stop working mid-field-day.
- Every response needs a verified GPS location, since a response with no location — or a spoofed one — can't be validated later.
- The final dataset has to land in a fixed, client-specified format: 2,500+ Excel columns, with brand-level answers coded across 60+ beverages.
- The people entering data are field interviewers under time pressure, not developers — the app has to survive app-kills, backtracking, and repeat taps without silently corrupting or duplicating data.
Goal: One app that runs the full brand-awareness/consumption questionnaire completely offline, hard-gates on a verified GPS fix at survey start, and produces clean, correctly-shaped data with no manual re-entry step.
Target users
- Primary: Field interviewers/surveyors running the questionnaire on a phone, door-to-door or via spot intercept.
- Secondary: Market-research operations staff who log into the web dashboard to monitor sync activity and pull exports; the beverage client's analysts who consume the final Excel file.
- Constraints: Low/mid-range Android devices in low- or zero-connectivity areas; non-technical field staff working quickly, respondent by respondent; an export format fixed by the client's existing reporting pipeline and not up for redesign.
The solution
A three-part system — a local-first mobile app that never depends on a live connection to function, a thin backend that accepts synced data and issues admin sessions, and a web dashboard for oversight and export.
Offline-first survey app
Expo Router screens read/write a shared Zustand store; every screen auto-saves to on-device SQLite before navigating away, so nothing is lost if the app closes, crashes, or loses signal mid-survey.
Sync & backend
A Node/Express API on Render accepts batched, idempotent syncs from the app and stores responses in MongoDB Atlas, tagged with an interviewer ID and a stable per-survey ID.
Admin web dashboard
A JWT-authenticated React/Vite portal shows live sync stats and lets staff export the full dataset into the client's exact Excel/CSV format.
Key features
Full survey flow. Screener → demographics → recruitment → unaided & aided brand awareness (BA1/BA2/BA3) → consumption funnel → consumption context → category & corporate approval → classification → thank-you.
GPS verification. Location capture hard-gated at survey start, re-checked at completion.
Draft auto-save and resume. Resume from any screen, after any interruption.
Duplicate-safe cloud sync. Survives double-taps and dropped-connection retries.
2,500+ column CSV/Excel export. 60+ brand mapping tables, matching the client's legacy format exactly.
Responsive brand grid. 3, 4 or 5 columns depending on screen width.
Admin dashboard. Live sync stats and one-click data export.
Tech stack
Mobile
- Expo SDK 56
- React Native 0.85.3
- React 19
- Expo Router (file-based navigation, typed routes)
- React Compiler
State & local storage
- Zustand 5
- expo-sqlite
- AsyncStorage
- NetInfo
Location & sharing
- expo-location
- expo-sharing
- expo-file-system
Data export
- SheetJS (xlsx)
Backend
- Node.js
- Express 5
- Mongoose 9
Auth & security
- JWT (jsonwebtoken)
- bcryptjs
- dotenv
- CORS
Database & hosting
- MongoDB Atlas
- Render (API)
- EAS Build (mobile)
Admin web dashboard
- React
- Vite
- Tailwind CSS
- Recharts
Tooling
- ESLint (eslint-config-expo)
- TypeScript project config
- Git
System architecture
Interviewer device
Expo/React Native app
- Survey screens (expo-router)
- Zustand store
- On-device SQLite (pending_surveys)
Local SQLite
cms_survey.db
- status: draft → pending → synced
- Guarded schema migrations
Express API
Node.js, Render
- /api/sync
- /api/stats
- /api/surveys
- /api/admin/login
Admin web portal
React + Vite + Tailwind + Recharts
- Login
- Dashboard stats
- Survey table
- Excel export
Admin portal ↔ Express API: JWT bearer token, 12h expiry
MongoDB Atlas
Mongoose models
- Survey (surveyId, surveyData, interviewerId, syncedAt)
- Admin (email, bcrypt password hash)
Mobile builds ship via EAS Build across development/preview/production profiles (Android APK today; iOS distribution not yet configured). The backend deploys straight from main to Render as a manual dashboard-configured Node service — no CI pipeline yet for backend or admin web.
An interviewer opens the app in the field with no signal, and starts a new survey once GPS is confirmed on. Every screen's answers merge into a shared Zustand store and auto-save to on-device SQLite through a serialized queue, so a double-tap on Next never creates two rows for the same respondent. GPS is captured again, non-blockingly, when the survey completes. Once the interviewer is back in range, tapping Sync on the Reports screen batches every pending row and POSTs it to /api/sync; the API pulls the interviewer ID and a client-generated surveyId out of each payload and performs an idempotent MongoDB upsert, so a retried request after a dropped response updates the existing document instead of inserting a duplicate. Separately, an admin logs into the web portal, receives a 12-hour JWT, and the dashboard calls /api/stats and /api/surveys to render live counts and drive the client's 2,500+ column Excel export.
System design highlights
Serialized auto-save queue kills duplicate drafts
A double-tap on Next/Finish before the first SQLite INSERT resolved let two calls both read draftId === null and both insert a new row for the same respondent.
Technical deep dive
- Classic check-then-act race: two near-simultaneous calls both see "no draft yet" before either write lands.
- Fix: every persistence write (draft autosave and the final thank-you submit) now runs through one serialized queue (withSurveySaveLock), so a second call always waits and sees the real draftId.
- The hook also reads state via useSurveyStore.getState() at write time rather than a stale React closure, so the freshest data is always what gets saved.
Idempotent cloud sync via a client-generated survey ID
Flaky field connections dropped sync responses; the app's retry then created duplicate MongoDB documents for the same completed survey.
Technical deep dive
- generateSurveyId() creates a locally-unique ID once, at survey start, and it's carried through every autosave, resume, and final submission.
- The server performs a bulkWrite of updateOne operations filtered by surveyId with upsert: true, so a resynced survey overwrites its own prior document instead of inserting a new one.
- The surveyId field is a sparse unique index — older app builds mid-rollout that don't send one yet fall back to a plain insert and keep working.
GPS tuned for field trust, not convenience
Field reports of survey locations landing 15–30 km off traced back to stale or network-assisted fixes being reused as "good enough."
Technical deep dive
- Accuracy.Highest forces the GPS chip itself rather than the faster wifi/network-assisted positioning that Balanced accuracy can silently fall back to.
- getCurrentPositionAsync has no built-in timeout, so a manual race against a timeout (5s, extended to 15s at survey start) prevents a stuck GPS search from hanging the interviewer indefinitely.
- A cached last-known position is only trusted as a fallback if it's both under 5 minutes old and under 500 m accuracy — a surveyor can cover ~50 km in a day, so an older "last known" fix is worse than no fix at all.
- Two gating strategies by context: a hard gate (location services + permission required) blocks starting a brand-new survey, while location capture during an in-progress survey is always best-effort and non-blocking.
Local-first storage with guarded schema migrations
The SQLite schema has grown twice since launch (added last_saved_route, then updated_at) without ever requiring an app reinstall.
Technical deep dive
- Every migration is a PRAGMA table_info check followed by a conditional ALTER TABLE ... ADD COLUMN, so existing installs on older schema versions upgrade safely instead of crashing.
- SQLite forbids a non-constant default (like CURRENT_TIMESTAMP) on ALTER TABLE ADD COLUMN, so new timestamp columns are added bare and then backfilled with a follow-up UPDATE.
A 2,500+ column export engine with one source of truth
The CSV/Excel exporter (csvMapper.js, ~2,500 lines) has to reproduce the client's exact legacy spreadsheet format, column for column.
Technical deep dive
- TARGET_HEADERS is one explicit array holding the client-specified column order — never auto-derived from the survey schema, so it can't silently drift out of alignment.
- Per-brand mapping tables translate answers for 60+ beverages into the correct BA2/BA3/BC11/BC12 columns.
- generateAndShareOldFormatCSV() reads every pending SQLite row, serializes it into the target format, and hands it off via expo-sharing for the interviewer to export directly from the device.
Also in the codebase
- Responsive brand-grid columns (3 / 4 / 5) driven by useWindowDimensions per screen, not a global constant.
- Sticky question headers with scroll-to-top on step navigation.
- Stale-answer cleanup: backtracking and changing an earlier answer strips now-invalid follow-up answers (e.g. BC4.3/BC4.5) so they can't linger and misalign the export.
- Age-gate branching: respondents aged 13–15 require parental consent instead of outright termination.
- Category and corporate brand-approval screening modules ahead of classification.
- Typed routes and React Compiler enabled via Expo's experimental flags.
Security
Auth & access
- bcrypt-hashed admin password
- JWT session tokens, 12h expiry
- Single admin login flow — interviewers never create accounts, so the app + backend address are the credential boundary
Data handling
- MongoDB connection string kept in an environment variable, never in source
- .env and node_modules excluded via .gitignore in both client and server
- Request body size capped (50 MB) for bulk survey payload uploads
Field-data integrity
- GPS hard-gated (location services + permission required) before a survey can start
- Idempotent surveyId-based upsert prevents duplicate/replay writes on sync retries
- Serialized local save queue prevents race-condition data loss
Challenges and trade-offs
| Challenge | Decision | Trade-off |
|---|---|---|
| Interviewers double-tapping Next/Finish created duplicate pending surveys in local SQLite | Serialize all local persistence writes through a single save-lock queue instead of just debouncing the UI | Every autosave and the final submit share one queue, so a slow write briefly delays the next screen transition — acceptable for a strictly one-respondent-at-a-time flow |
| Flaky field connectivity dropped sync responses, and retries created duplicate MongoDB documents | Generate a stable surveyId client-side at survey start and upsert on it server-side via bulkWrite, instead of a plain insert | Requires a sparse unique index plus a fallback plain-insert path to keep older app builds working mid-rollout |
| GPS fixes were reported 15–30 km off in the field | Force Accuracy.Highest (GPS chip only, no network-assisted fallback), extend the fix window to 15s, and only trust a cached last-known fix if it's under 5 minutes old and 500 m accurate | Slower or no fix indoors/in dead zones — mitigated by treating GPS as best-effort and non-blocking rather than a hard mid-survey requirement |
| A single ~2,500-line CSV mapper has to reproduce a client-specified 2,500+ column legacy format exactly | Keep one explicit TARGET_HEADERS array plus per-brand mapping tables as the single source of truth, updated in lockstep with every survey question change | No abstraction over the column mapping — verbose and manually maintained, but any indirection risks silently misaligning a client-facing export |
| Interviewers needed to work in areas with no signal at all | Local-first architecture: every screen writes to on-device SQLite immediately; sync is a separate, explicit step | Two sources of truth (local draft vs. synced cloud record) that have to be reconciled through an explicit status lifecycle (draft → pending → synced), rather than one always-online system |
Results
2,500+
Client-specified export columns matched exactly
60+
Beverage brands tracked
20
Survey flow screens (screener → thank-you)
5,000+
Surveys collected in the field
200–300
Active field interviewers across the country
All
Provinces and districts covered
~4 months
Solo build timeline (May–Sep 2026, 44 commits)
100%
Of data entry works with zero connectivity
What I learned
- Treat any "check-then-act" state read (like draftId === null) as a race condition by default on UI that allows rapid repeat taps — not just as something a debounce fixes.
- Idempotency has to be designed at the write boundary — a stable client-generated ID plus a server-side upsert — not patched in after duplicates are already showing up in production data.
- On field hardware, "most accurate" and "most available" are different GPS settings entirely; pick deliberately per use case, and always pair a hard gate with a non-blocking fallback elsewhere.
- A client-specified legacy export format is a contract, not a style choice — the column list itself is the spec, so keep exactly one explicit source of truth for it instead of deriving it.
- Local-first apps need a real small state machine (draft / pending / synced), not a boolean "is this saved," to reason correctly about what a sync retry should do.
What's next
- Add authorization middleware to the data endpoints (/api/sync, /api/stats, /api/surveys) so they require the same JWT the admin portal already issues — closing the gap between the documented security rule ("every data endpoint must require login") and the current implementation.
- Move from a single shared admin account to per-interviewer accounts with scoped permissions.
- Replace the two hardcoded admin-dashboard stats (active surveyors, average survey time) with real calculated values.
- Set up iOS distribution (Android-only today) and a CI pipeline for the backend and admin web portal, both currently manual deploys.
- Build out the still-placeholder admin portal sections (Interviewers, Municipality, other report views).
